Baumuller b maXX 4100 Series - Cable Mains - Function Module (UME, SRM and SEA); Cable Mains - Charge Circuit; Cable Control Voltage Supply;Signals; Cable - Signals X100-3 and X100-4

Cabling
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09 Baumüller Nürnberg GmbH
114
of 142
11.1
11.1.4 Cable mains - function module (UME, SRM and SEA)
1)
Possible cross section
Use a shielded Baumüller cable, optical shield overlap > 85 %.
For UL conform machines/installation you must use UL certified circuit cables.
2)
Only with Baumüller cables with this maximum length and when using a Baumüller mains filter you can assume, that the compliance
with the EMC regulation is fulfilled.
11.1.5 Cable mains - charge circuit
1)
Possible cross section
Use a shielded Baumüller cable, optical shield overlap > 85 %.
For UL conform machines/installation you must use UL certified circuit cables.
2)
Only with Baumüller cables with this maximum length and when using a Baumüller mains filter you can assume, that the compliance
with the EMC regulation is fulfilled.
11.1.6 Cable control voltage supply/signals
1)
The installing of the cables is user-defined.
2)
The length of the cable has no influence on the compliance to the EMC regulation.
11.1.7 Cable - signals X100-3 and X100-4
1)
Cables longer than 3 m must be screened.
Cross section
1)
≤ 1,5 mm
2
Maximum length
2)
user-defined
Connection to the device without/with wire end ferrules (plug-in terminal)
Cross section
1)
1.0 - 1,5 mm
2
Maximum length
2)
user-defined
Connection to the device without/with wire end ferrules (plug-in terminal)
Cross section
1)
≤ 1.5 mm
2
Maximum length
2)
user-defined
Connection to device with /without wire end ferrules (plug-in terminal)
Cross section ≤ 1,5 mm
2
Maximum length
1)
3 m
Connection to the device without/with wire end ferrules (plug-in terminal)
