Preparing for mounting
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09 Baumüller Nürnberg GmbH
52
of 142
6.2
6.2 Preparing for mounting
Based on the planning documents and the drilling pattern (see ZDrilling patterns– from
page 53), the cutout sections and the positions of the attachment drill holes can be deter-
mined.
h Preparing drill holes and cutout sections.
NOTICE!
Property damage due to conductive contamination.
Therefore:
m When performing installation work of any kind, it must be ensured that no foreign
material (e.g. drill shavings, copper strands, etc.) gets into the device as a result.
m If possible, the drilling of the holes should be done before mounting the device and
the configuring of the cables should take place outside of the control cabinet. If this
is not possible, the device must be appropriately covered.
Remove this covering again prior to start!
CAUTION!
Eye injury due to flung particles.
Metal particles are flung when making the drill holes and the cutout sections.
Therefore:
Wear protective eye wear!
