Baumuller b maXX 4100 Series - Requirements for the Screwing (UL)

Connection diagrams
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09 Baumüller Nürnberg GmbH
80
of 142
7.18
7.18.2 Requirements for the screwing (UL)
in case you consider UL 508 C: refer to the torques specified in ZConnector data of con-
nections– from page 78.
X11 Max. cable-Ø Connection technology Loading
BM4135
BM4145
BM4163
1.5 - 2.5 mm
2
plug-in contact X11-1 to X11-5:
H07 to 1000 V
see ZPre-charge protec-
tion– on page 117
A: X1 to C: X1
1)
Cable-Ø Connection technology Load capacity
BM4135
BM4145
BM4163
0.75 - 2.5 mm
2
plug-in contact X1-1, X1-2 and X1-3:
H07 to 1000 V
max. 1.0 A
D: X1 Cable-Ø Connection technology Load capacity
(SELV/PELV) BM4135
BM4145
BM4163
0.75 - 1.5 mm
2
plug-in contact X1-5 to X1-10:
in case you consider UL
508 C: max. 1.0 A
NOTE
Further information according the function module BM4-F-DIO/FIO-xx are to be taken
from the manual BM4-F-DIO/FIO-xx.
