Troubleshooting and fault correction
Operation manual b maXX BM4100 (NWR)
Document no.: 5.04052.09
97
of 142
9
P203 Error Proprog communication
P0204 Error in function or option modules
Error No. Meaning Reaction Troubleshooting
32 Timeout protocol adjustable RestartBM4100 (NWR)
33 Protocol structure adjustable
34 Wrong module type adjustable Contact Baumüller Nürnberg GmbH
35 Too many data in the telegram adjustable
36 Not enough data in telegram adjustable
37 Invalid operand adjustable
38 Invalid memory type adjustable Test RAM
39 Invalid operand address adjustable Enter valid address
40 Value less than the minimum value adjustable Check and adjust data set
41 Value greater than the maximum value adjustable
42 Parameter is write-protected adjustable
43 Parameters in this operation state not writable adjustable Check operating condition and parameterization
44 Invalid parameter value adjustable Enter with a valid value
45 Communication error
ProDrive ↔ controller
adjustable Establish connection again or set parameter P0290 to
0.
46 to 47 reserved, not assigned = 0
Error No. Meaning Reaction Troubleshooting
48 Error in function module A 3rd level
error
see ZError in function module A to E– on page 101 (=
3rd level)
49 Error in function module B
50 Error in function module C
51 Error in function module D
52 Error in function module E
53 Error in option module G
54 Error in option module H
55 to 58 reserved, not assigned = 0
59 Timeout when waiting for the RST signal of the
slaves
IS Restart BM4100 (NWR)
60 CRC error in SPI transmission
Module f controller
adjustable Error indicates high EMC interferences; please reduce
these.
Contact Baumüller Nürnberg GmbH.
61 CRC error in SPI transmission
Controller f module
adjustable
62 to 63 reserved, not assigned = 0
