Connecting the Console/Comm Port
The serial console interface is an RS-232 port that enables a connection to a PC or
terminal for monitoring and configuring the switch. You can also connect this port
to an external modem to enable remote dial-in management of the switch. The
port is a male DB-9 connector, implemented as a data communication equipment
(DCE) connection.
To use the Console/Comm port, you need the following equipment:
• A terminal or TTY-compatible terminal, or a portable computer with a serial
port and the ability to emulate a terminal
The terminal should have the following settings:
- 9600 baud
- No parity
- 8 bits
- 1 stop bit
- Window Terminal Emulator option set to NO
- Terminal Preferences: function, arrow, and control keys active
- Buffer size set to 24
• A UL-listed straight-through RS-232 cable with a female DB-9 connector for
the console port on the switch
The other end of the cable must have a connector appropriate to the serial port
on your computer or terminal. (Most terminals or computers use a male
DB-25 connector.)
Any cable connected to the console port must be shielded to comply with
emissions regulations and requirements.
See “DB-9 (RS-232-D) Console/Comm Port Connector,” on page D-1 for a
description of the pin assignments.
To connect a terminal to the console port, follow these steps:
1.
Set the terminal protocol as described previously.
2.
Connect the terminal (or a computer in terminal-emulation mode) to the
console port using the RS-232 cable.
