Bay Networks BayStack 350 - Figure 3-38. Self-Test Screen after Resetting to Factory Default Settings

Using the BayStack 350 10/100/1000 Series Switch
3-80
304376-B Rev 00
The Reset to Default Settings option takes approximately 5 seconds to complete.
During this time, the switch initiates a self-test that comprises various diagnostic
routines and subtests. The LEDs display various patterns to indicate that the
subtests are in progress.
The results of the self-test are displayed briefly (5 or 10 seconds) in the Self-Test
screen (Figure 3-38
), which is followed by the Bay Networks logo screen
(Figure 3-39
).
.
Figure 3-38. Self-Test Screen After Resetting to Factory Default Settings
BayStack 350-24T Self-Test
CPU RAM test ... Pass
ASIC addressing test ... Pass
ASIC buffer RAM test ... Pass
Port internal loopback test ... Pass
Self-test complete.
