Using the BayStack 350 10/100/1000 Series Switch
3-12
304376-B Rev 00
SNMP Configuration
The SNMP Configuration screen (Figure 3-4) allows you to set or modify the
SNMP configuration parameters.
Choose SNMP Configuration (or press m) from the main menu to open the SNMP
Configuration screen.
Figure 3-4. SNMP Configuration Screen
SNMP Configuration
Read-Only Community String: [ public ]
Read-Write Community String: [ private ]
Trap #1 IP Address: [ 0.0.0.0 ]
Community String: [ ]
Trap #2 IP Address: [ 0.0.0.0 ]
Community String: [ ]
Trap #3 IP Address: [ 0.0.0.0 ]
Community String: [ ]
Trap #4 IP Address: [ 0.0.0.0 ]
Community String: [ ]
Authentication Trap: [ Enabled ]
Link Up/Down Trap: [ Enabled ]
Enter text, press <Return> or <Enter> when complete.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
