Trunk Configuration Screen for Switch S4
As shown in Figure 1-33
, switch S4 is set up with one trunk configuration (T5).
This trunk connects directly to switch S1.
As in the previous screen examples, to set up a trunk configuration choose
MultiLink Trunk Configuration from the MultiLink Trunk Configuration Menu
screen.
Figure 1-38
shows the MultiLink Trunk Configuration screen for switch S4.
Figure 1-38. MultiLink Trunk Configuration Screen for Switch S4
MultiLink Trunk Configuration
Trunk Trunk Members STP Learning Trunk Mode Trunk Status
----- ---------------------------- ------------ --------------- ------------
1 [ 5 ][ 11 ][ ][ ] [ Normal ] Basic [ Enabled ]
2 [ ][ ][ ][ ] [ Normal ] Basic [ Disabled ]
3 [ ][ ][ ][ ] [ Normal ] Basic [ Disabled ]
4 [ ][ ][ ][ ] [ Normal ] Basic [ Disabled ]
5 [ ][ ][ ][ ] [ Normal ] Basic [ Disabled ]
6 [ ][ ][ ][ ] [ Normal ] Basic [ Disabled ]
Trunk Trunk Name
----- -------------------
1 [ S4:T5 to S1 ]
2 [ Trunk #2 ]
3 [ Trunk #3 ]
4 [ Trunk #4 ]
5 [ Trunk #5 ]
6 [ Trunk #6 ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
