Using the BayStack 350 10/100/1000 Series Switch
3-4
304376-B Rev 00
Main Menu
This section describes the options available from the CI main menu (Figure 3-2).
The CI screens and submenus for these options are described in the following
sections.
Figure 3-2. Console Interface Main Menu
Table 3-1 describes the CI main menu options.
Table 3-1. Console Interface Main Menu Options
Option Description
IP Configuration/Setup
Displays the IP Configuration/Setup screen (see “
IP Configuration/Setup” on
page 3-7
). This screen allows you to set or modify IP configuration parameters.
SNMP Configuration
Displays the SNMP Configuration screen (see “
SNMP Configuration” on
page 3-12
). This screen allows you to set or modify the SNMP read-only
community and read-write community strings, enable or disable the
authentication trap, set the IP address of trap receivers, and set the trap
community strings.
(continued)
BayStack 350-24T Main Menu
IP Configuration/Setup...
SNMP Configuration...
System Characteristics...
Switch Configuration...
Console/Comm Port Configuration...
Spanning Tree Configuration...
TELNET Configuration...
Software Download...
Display Event Log
Reset
Reset to Default Settings
Logout
Use arrow keys to highlight option, press <Return> or <Enter> to select option.
kombk.book Page 4 Thursday, February 18, 1999 10:59 AM
