Using the BayStack 350 10/100/1000 Series Switch
1-46
304376-B Rev 00
Trunk Configuration Screen Examples
This section shows examples of the MultiLink Trunk Configuration screens for
the client/server configuration example shown in Figure 1-33
on page 1-45. The
screens show how you could set up the trunk configuration screens for switches
S1 to S4. For more information, see “Spanning Tree Considerations
” on
page 1-57
, and “MultiLink Trunk Configuration” on page 3-35.
Trunk Configuration Screen for Switch S1
Switch S1 is set up with five trunk configurations: T1, T2, T3, T4, and T5.
Setting up the Trunk Configuration For S1:
To set up the trunk configuration, choose MultiLink Trunk Configuration
(or press t) from the MultiLink Trunk Configuration Menu screen (Figure 1-34
).
Figure 1-34. Choosing the MultiLink Trunk Configuration Screen
MultiLink Trunk Configuration Menu
MultiLink Trunk Configuration...
MultiLink Trunk Utilization...
Return to Switch Configuration Menu
Use arrow keys to highlight option, press <Return> or <Enter> to select option.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
