Using the Console Interface
304376-B Rev 00
3-39
MultiLink Trunk Utilization Screen
The MultiLink Trunk Utilization screen (Figure 3-18
and Figure 3-19) allows you
to monitor the percentage of bandwidth used by configured trunk members. You
can choose the type of traffic to monitor.
Figure 3-18
shows an example of bandwidth utilization rates for the trunk member
ports configured in Figure 3-17
. Because two screens are required to show all of
the configured trunks (up to six), the screen prompts users to Press [Ctrl]-N to
view trunks five and six.
Choose MultiLink Trunk Utilization (or press u) from the MultiLink Trunk
Configuration Menu screen to open the MultiLink Trunk Utilization screen.
Figure 3-18. MultiLink Trunk Utilization Screen (1 of 2)
MultiLink Trunk Utilization
Trunk Traffic Type Port Last 5 Minutes Last 30 Minutes Last Hour
----- ------------- ---- -------------- --------------- ---------
1 [ Rx and Tx ] 6 90.0% 70.0% 90.0%
7 20.0% 55.0% 80.0%
9 35.0% 45.0% 45.0%
17 85.0% 35.0% 20.0%
2 [ Rx and Tx ] 25 45.0% 45.0% 50.0%
26 25.0% 70.0% 35.0%
3 [ Rx and Tx ] 13 35.0% 35.0% 50.0%
14 30.0% 80.0% 70.0%
4 [ Rx and Tx ] 19 40.0% 35.0% 75.0%
20 25.0% 70.0% 85.0%
More...
Press Ctrl-N to display utilization for trunks 5-6.
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
