BayStack 350 10/100/1000 Series Switches
304376-B Rev 00
1-31
Figure 1-22. VLAN Port Configuration Screen Example
VLAN Workgroup Summary
This section summarizes the VLAN workgroup examples discussed in the
previous sections of this chapter.
As shown in Figure 1-23
, switch S1 (a BayStack 350-12T switch) is configured
with multiple VLANs:
• Ports 1, 6, 11, and 12 are in VLAN 1.
• Ports 2, 3, 4, 7, and 10 are in VLAN 2.
• Port 8 is in VLAN 3.
Because S4 (a non-802.1Q switch) does not support 802.1Q tagging, a single
switch port on each switch must be utilized for each VLAN (see “VLANS
Spanning Multiple Untagged Switches” on page 1-24).
VLAN Port Configuration
Port: [ 8 ]
Filter Tagged Frames: [ No ]
Filter Untagged Frames: [ No ]
Filter Unregistered Frames: [ No ]
Port Name: [ Library Sharing ]
PVID: [ 3 ]
Port Priority: [ 0 ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
