Using the BayStack 350 10/100/1000 Series Switch
C-8
304376-B Rev 00
Configuring IGMP Snooping
This section shows how to configure switch ports for IGMP Snooping or to
modify existing IGMP Snooping ports (see Figure C-7
to Figure C-9).
Choose IGMP Configuration (or press g) from the Switch Configuration Menu
screen to open the IGMP Configuration screen.
Figure C-7. Configuring IGMP Snooping (1 of 3)
Yes
No
No
BS35053A
Are VLANs
created/port members
configured?
Is the
Snooping field set
correctly?
Yes
Is
Snooping field
set?
Yes
Yes
No
2
Is
the Proxy field set
correctly?
No
2
IGMP Configuration screen
Go to VLAN flowchart. Create VLANs/
configure port members, as required.
Set the correct value
for the Snooping field.
Set the correct value
for the Proxy field.
Off-page reference
On-page reference
Key
kombk.book Page 8 Thursday, February 18, 1999 10:59 AM
