Using the Console Interface
304376-B Rev 00
3-29
Figure 3-12. Traffic Class Configuration Screen
Table 3-11 describes the Traffic Class Configuration screen fields.
Table 3-11. Traffic Class Configuration Screen Fields
Field Description
User Priority
Column header for the read-only fields that indicate the user-priority values
from priority 0 to priority 7. These values are derived from the three-bit field in
the header of 802.1Q tagged frames (see “IEEE 802.1Q Tagging” on
page 1-19).
Traffic Class
Column header for the eight user-configurable fields that correspond to the
adjacent user priority levels.
Default Value: Low
Range: Low, High
Traffic Class Configuration
User Priority Traffic Class
------------- -------------
Priority 0: [ Low ]
Priority 1: [ Low ]
Priority 2: [ Low ]
Priority 3: [ Low ]
Priority 4: [ Low ]
Priority 5: [ Low ]
Priority 6: [ Low ]
Priority 7: [ Low ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
