Using the BayStack 350 10/100/1000 Series Switch
1-30
304376-B Rev 00
Figure 1-21. Default VLAN Port Configuration Screen Example
Figure 1-22 shows the VLAN Port Configuration screen after it is configured to
support the PVID assignment for port 8, as shown in Figure 1-18
(the Port Name
field is optional).
The PVID/VLAN association for VLAN 3 is now PVID = 3.
VLAN Port Configuration
Port: [ 1 ]
Filter Tagged Frames: [ No ]
Filter Untagged Frames: [ No ]
Filter Unregistered Frames: [ No ]
Port Name: [ Port #1 ]
PVID: [ 1 ]
Port Priority: [ 0 ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
