BayStack 350 10/100/1000 Series Switches
304376-B Rev 00
1-29
Ports 2, 4, 6, 8, 10, and 11 are now untagged members of VLAN 3 as shown in
Figure 1-18
on page 1-27.
Figure 1-20. VLAN Configuration Screen Example
To configure the PVID (port VLAN identifier) for Port 8, follow these steps:
1.
From the VLAN Configuration screen, press [Ctrl]-R to return to the
VLAN Configuration Menu.
2.
From the VLAN Configuration Menu, select VLAN Port Configuration
(or press c).
The default VLAN Port Configuration screen opens (Figure 1-21
).
The VLAN Port Configuration screen settings shown in Figure 1-21
are default
settings.
VLAN Configuration
Create a VLAN: [ 3 ]
Delete a VLAN: [ ]
VLAN Name: [ Michele's VLAN ]
Port Numbers
1-5 6-10 11-12
----- ----- -----
-U-U- U-U-U U-
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
