Using the BayStack 350 10/100/1000 Series Switch
2-18
304376-B Rev 00
This selection displays the IP Configuration/Setup screen (Figure ).
IP Configuration/Setup Screen
4.
Enter the IP address of the switch in the In-Band IP Address field, then
press [Return].
Note:
The IP interface of the BayStack 350 switch is only on VLAN 1. You
can manage the switch only from VLAN 1 (or via routers that connect VLAN
1 to the network management station).
Note:
IP addresses are written as four decimal numbers (for example,
123.123.123.123). Each decimal number represents an 8-bit octet. When
strung together, the four octets form the 32-bit Internet address. This is
called dotted-decimal notation. The largest possible value of a field in a
dotted-decimal number is 255, which represents an octet of all ones.
IP Configuration/Setup
BootP Request Mode: [ BootP When Needed ]
Configurable In Use Last BootP
------------------- --------------- --------------
-
In-Band IP Address: [ 0.0.0.0 ] 0.0.0.0 0.0.0.0
In-Band Subnet Mask: [ 0.0.0.0 ] 0.0.0.0 0.0.0.0
Default Gateway: [ 0.0.0.0 ] 0.0.0.0 0.0.0.0
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
