Using the BayStack 350 10/100/1000 Series Switch
3-8
304376-B Rev 00
Figure 3-3. IP Configuration/Setup Screen
Table 3-2 describes the IP Configuration/Setup screen fields.
Table 3-2. IP Configuration/Setup Screen Fields
Field Description
BootP Request Mode
One of four modes of operation for BootP. (See “
Choosing a BootP Request Mode”
on page 3-9
for details about the four modes.)
Default Value: BootP Disabled
Range: BootP When Needed, BootP Always, BootP Disabled, BootP or
Last Address
Configurable
Column header for the user-configurable fields in this screen.
In Use
Column header for the read-only fields in this screen. The read-only data displayed
in this column represents data that is currently in use.
(continued)
IP Configuration/Setup
BootP Request Mode: [ BootP When Needed ]
Configurable In Use Last BootP
------------------- --------------- ---------------
In-Band IP Address: [ 0.0.0.0 ] 0.0.0.0 0.0.0.0
In-Band Subnet Mask: [ 0.0.0.0 ] 0.0.0.0 0.0.0.0
Default Gateway: [ 0.0.0.0 ] 0.0.0.0 0.0.0.0
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
