Using the Console Interface
304376-B Rev 00
3-19
Figure 3-7. MAC Address Table Screen
Table 3-6 describes the MAC Address Table
screen fields.
Table 3-6. MAC Address Table Screen Fields
Field Description
Aging Time
Specifies how long a learned MAC address remains in the switch’s
forwarding database. If an entry is inactive for a period of time that exceeds
the specified aging time, the address is removed.
Default Value: 300 seconds
Range: 10 to 1,000,000 seconds
Find an Address
Allows the user to search for a specific MAC address.
Default Value: 00-00-00-00-00-00 (no MAC address assigned)
Range: 00-00-00-00-00-00 to FF-FF-FF-FF-FF-FF
(continued)
MAC Address Table
Aging Time: [ 300 seconds ]
Find an Address: [ 00-00-00-00-00-00 ]
Port Mirroring Address A: [ 00-44-55-44-55-22 ]
Port Mirroring Address B: [ 00-33-44-33-22-44 ]
00-60-FD-00-02-30
00-00-A2-85-BB-26 Port: 1
00-60-FD-12-02-15 Port: 1
00-08-C7-1D-4F-38 Trunk:3
End of Address Table. Press Ctrl-P to see previous display.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
