Using the Console Interface
304376-B Rev 00
3-37
Figure 3-17. MultiLink Trunk Configuration Screen
Table 3-15 describes the MultiLink Trunk Configuration screen fields.
Table 3-15. MultiLink Trunk Configuration Screen Fields
Field Description
Trunk
Column header for the read-only fields in this screen. The read-only data displayed in the
Trunk column indicates the trunk (1 to 6) that corresponds to the switch ports specified in
the user-configurable Trunk Members fields.
Trunk Members
The Trunk Members column contains fields in each row that can be configured to create
the corresponding trunk. Each switch port can only be a member of a single trunk. The
appropriate trunk number for each trunk member configured within this field is shown
adjacent to the corresponding switch port in the following screens: Port Configuration
screen, and Spanning Tree Configuration screen. Gigabit ports cannot be configured as
trunk members.
Default Value: blank field
Range: 1 to 28 (depending on model type)
(continued)
MultiLink Trunk Configuration
Trunk Trunk Members STP Learning Trunk Mode Trunk Status
----- ---------------------------- ------------ --------------- ------------
1 [ 6 ][ 7 ][ 9 ][ 17 ] [ Normal ] Basic [ Enabled ]
2 [ 25 ][ 26 ][ ][ ] [ Normal ] Basic [ Enabled ]
3 [ 13 ][ 14 ][ ][ ] [ Normal ] Basic [ Enabled ]
4 [ 19 ][ 20 ][ ][ ] [ Normal ] Basic [ Enabled ]
5 [ 22 ][ 23 ][ ][ ] [ Fast ] Basic [ Enabled ]
6 [ ][ ][ ][ ] [ Disabled ] Basic [ Disabled ]
Trunk Trunk Name
----- -------------------
1 [ S1:T1 to FS2 ]
2 [ S1:T2 to S2 ]
3 [ S1:T3 to S2 ]
4 [ S1:T4 to S3 ]
5 [ S1:T5 to S4 ]
6 [ Trunk #6 ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
