Using the BayStack 350 10/100/1000 Series Switch
3-44
304376-B Rev 00
Table 3-18. Monitoring Modes
Fields Description
Port-Based Fields:
Disabled Default Value: for this feature.
-> Port X Monitor all traffic received by Port X.
Port X -> Monitor all traffic transmitted by Port X.
<-> Port X Monitor all traffic received and transmitted by Port X.
-> Port X or Port Y -> Monitor all traffic received by Port X or transmitted by Port Y.
-> Port X and Port Y -> Monitor all traffic received by Port X (destined to Port Y) and then
transmitted by Port Y.
<-> Port X and Port Y <-> Monitor all traffic received/transmitted by Port X and received/
transmitted by Port Y.
Address-Based Fields:
Disabled Default Value: for this feature.
Address A -> any Address Monitor all traffic transmitted from Address A to any address.
any Address -> Address A Monitor all traffic received by Address A from any address.
<-> Address A Monitor all traffic received by or transmitted by Address A.
Address A -> Address B Monitor all traffic transmitted by Address A to Address B.
Address A <-> Address B Monitor all traffic between Address A and Address B (conversation
between the two stations).
kombk.book Page 44 Thursday, February 18, 1999 10:59 AM
