7 Procedural Instructions on the TSC
Infusomat® compact
plus
P 1.0 7 - 5
EN
For internal use, only
4. Vent test setup, for position of the three-way cocks please see
Fig. 7 - 3, start infusion and deliver first of all in to an open
system (without pressure gauge).
Upstream:
5. Push roller clamp of the Intrafix Primeline up to approx. 30 cm
before the pump and close the roller clamp or pinch the Intrafix
Primeline between the container and 30 cm before the pump.
An alarm is output.
6. Open roller clamp.
Downstream:
7. Switch over three-way valve, please see Fig. 7 - 4, and deliver
towards the pressure gauge.
Read off maximum value on the pressure gauge upon an alarm
and before an automatic pressure reduction and compare with
the specifications in the TSC.
8. Check all pressure stages listed in the TSC and document
values.
Do not reduce pressure.
Pressure limitation, mechanical
P
max
1. Deactivate electronic pressure cut-off:
a) Via "Menu" button and arrow keys, select the "Settings"
menu item and confirm with "OK".
b) Select "Service" and confirm device code with "OK".
c) Confirm selection of "Pressure" "Off" with "OK".
(pressure "off" will be active for 5 minutes)
2. Input a delivery rate according to the checklist.
Enter a sufficiently large VTBI, e.g. 50ml (required for infusion
lines other than SafeSet).
3. Switch over three-way valve, please see Fig. 7 - 4, and deliver
towards the pressure gauge for 3 minutes.
NOTICE
Do not use an Intrafix Primeline with an upstream "Y" site. The
back check-valve associated with the upstream "Y" site may
skew mechanical pressure limitation test results.
