Object description and parameterization
EL72x1-901x230 Version: 1.9
Index 1C12 RxPDO assign
Index (hex) Name Meaning Data type Flags Default
1C12:0 RxPDO assign PDO Assign Outputs UINT8 RW 0x02 (2
dec
)
1C12:01 Subindex 001 1. allocated RxPDO (contains the index of the associ-
ated RxPDO mapping object)
UINT16 RW 0x1600
(5632
dec
)
1C12:02 Subindex 002 2. allocated RxPDO (contains the index of the associ-
ated RxPDO mapping object)
UINT16 RW 0x1601
(5633
dec
)
1C12:03 Subindex 003 3. allocated RxPDO (contains the index of the associ-
ated RxPDO mapping object)
UINT16 RW 0x0000 (0
dec
)
1C12:04 Subindex 004 4. allocated RxPDO (contains the index of the associ-
ated RxPDO mapping object)
UINT16 RW 0x0000 (0
dec
)
1C12:05 Subindex 005 5. allocated RxPDO (contains the index of the associ-
ated RxPDO mapping object)
UINT16 RW 0x0000 (0
dec
)
1C12:06 Subindex 006 6. allocated RxPDO (contains the index of the associ-
ated RxPDO mapping object)
UINT16 RW 0x0000 (0
dec
)
1C12:07 Subindex 007 7. allocated RxPDO (contains the index of the associ-
ated RxPDO mapping object)
UINT16 RW 0x0000 (0
dec
)
1C12:08 Subindex 008 8. allocated RxPDO (contains the index of the associ-
ated RxPDO mapping object)
UINT16 RW 0x0000 (0
dec
)
Index 1C13 TxPDO assign
Index Name Meaning Data type Flags Default
1C13:0 TxPDO assign PDO Assign Inputs UINT8 RW 0x02 (2
dec
)
1C13:01 Subindex 001 1. allocated TxPDO (contains the index of the associ-
ated TxPDO mapping object)
UINT16 RW 0x1A00
(6656
dec
)
1C13:02 Subindex 002 2. allocated TxPDO (contains the index of the associ-
ated TxPDO mapping object)
UINT16 RW 0x1A01
(6657
dec
)
1C13:03 Subindex 003 3. allocated TxPDO (contains the index of the associ-
ated TxPDO mapping object)
UINT16 RW 0x0000 (0
dec
)
1C13:04 Subindex 004 4. allocated TxPDO (contains the index of the associ-
ated TxPDO mapping object)
UINT16 RW 0x0000 (0
dec
)
1C13:05 Subindex 005 5. allocated TxPDO (contains the index of the associ-
ated TxPDO mapping object)
UINT16 RW 0x0000 (0
dec
)
1C13:06 Subindex 006 6. allocated TxPDO (contains the index of the associ-
ated TxPDO mapping object)
UINT16 RW 0x0000 (0
dec
)
1C13:07 Subindex 007 7. allocated TxPDO (contains the index of the associ-
ated TxPDO mapping object)
UINT16 RW 0x0000 (0
dec
)
1C13:08 Subindex 008 8. allocated TxPDO (contains the index of the associ-
ated TxPDO mapping object)
UINT16 RW 0x0000 (0
dec
)
1C13:09 Subindex 009 9. allocated TxPDO (contains the index of the associ-
ated TxPDO mapping object)
UINT16 RW 0x0000 (0
dec
)
1C13:0A Subindex 010 10. allocated TxPDO (contains the index of the associ-
ated TxPDO mapping object)
UINT16 RW 0x0000 (0
dec
)
