Beckhoff EP31 Series User Manual

Configuration
EP31xx 107Version: 2.4
Index (hex) Name Flags Default value
8010:06 Enable filter RW 0x00 (0
dec
)
8010:07 Enable limit 1 RW 0x00 (0
dec
)
8010:08 Enable limit 2 RW 0x00 (0
dec
)
8010:0A Enable user calibration RW 0x00 (0
dec
)
8010:0B Enable vendor calibration RW 0x01 (1
dec
)
8010:0E Swap limit bits RW 0x00 (0
dec
)
8010:11 User scale offset RW 0x0000 (0
dec
)
8010:12 User scale gain RW 0x00010000 (65536
dec
)
8010:13 Limit 1 RW 0x0000 (0
dec
)
8010:14 Limit 2 RW 0x0000 (0
dec
)
8010:15 Filter settings RW 0x0000 (0
dec
)
8010:17 User calibration offset RW 0x0000 (0
dec
)
8010:18 User calibration gain RW 0x4000 (16384
dec
)
801E:0 [}137]
Subindex AI internal data RO 0x01 (1
dec
)
801E:01 ADC raw value RO 0x0000 (0
dec
)
801F:0 [}137]
Subindex AI vendor data RW 0x06 (6
dec
)
801F:01 R0 Offset RW 0x0000 (0
dec
)
801F:02 R0 Gain RW 0x0000 (0
dec
)
801F:03 R1 Offset RW 0x0000 (0
dec
)
801F:04 R1 Gain RW 0x0000 (0
dec
)
801F:05 R2 Offset RW 0x0000 (0
dec
)
801F:06 R2 Gain RW 0x4000 (16384
dec
)
8020:0 [}126]
Subindex AI Settings RW 0x18 (24
dec
)
8020:01 Enable user scale RW 0x00 (0
dec
)
8020:02 Presentation RW 0x00 (0
dec
)
8020:05 Siemens bits RW 0x00 (0
dec
)
8020:06 Enable filter RW 0x01 (1
dec
)
8020:07 Enable limit 1 RW 0x00 (0
dec
)
8020:08 Enable limit 2 RW 0x00 (0
dec
)
8020:0A Enable user calibration RW 0x00 (0
dec
)
8020:0B Enable vendor calibration RW 0x01 (1
dec
)
8020:0E Swap limit bits RW 0x00 (0
dec
)
8020:11 User scale offset RW 0x0000 (0
dec
)
8020:12 User scale gain RW 0x00010000 (65536
dec
)
8020:13 Limit 1 RW 0x0000 (0
dec
)
8020:14 Limit 2 RW 0x0000 (0
dec
)
8020:15 Filter settings RW 0x0000 (0
dec
)
8020:17 User calibration offset RW 0x0000 (0
dec
)
8020:18 User calibration gain RW 0x0000 (0
dec
)
802E:0 [}137]
Subindex AI internal data RO 0x01 (1
dec
)
802E:01 ADC raw value RO 0x0000 (0
dec
)
802F:0 [}137]
Subindex AI vendor data RW 0x06 (6
dec
)
802F:01 R0 Offset RW 0x0000 (0
dec
)
802F:02 R0 Gain RW 0x0000 (0
dec
)
802F:03 R1 Offset RW 0x0000 (0
dec
)
802F:04 R1 Gain RW 0x0000 (0
dec
)
802F:05 R2 Offset RW 0x0000 (0
dec
)
802F:06 R2 Gain RW 0x0000 (0
dec
)
8030:0 [}127]
Subindex AI Settings RW 0x18 (24
dec
)
8030:01 Enable user scale RW 0x00 (0
dec
)
8030:02 Presentation RW 0x00 (0
dec
)
8030:05 Siemens bits RW 0x00 (0
dec
)
8030:06 Enable filter RW 0x01 (1
dec
)
8030:07 Enable limit 1 RW 0x00 (0
dec
)
8030:08 Enable limit 2 RW 0x00 (0
dec
)
8030:0A Enable user calibration RW 0x00 (0
dec
)
8030:0B Enable vendor calibration RW 0x01 (1
dec
)
8030:0E Swap limit bits RW 0x00 (0
dec
)
