89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page D-15
© Honeywell International Inc. Do not copy without express permission of Honeywell.
NOTES:
1. ALL WIRES TO BE 22 AWG OR GREATER UNLESS OTHERWISE NOTED.
2. IF THE GPS ARINC 429 IN 1 PORT (P1001-48 AND -49) IS ALREADY USED FOR ANOTHER PURPOSE.
THE GPS ARINC 429 IN 2 PORT (P1001-50 AND -51) MAY BE CONNECTED INSTEAD.
3. THE SKYWATCH POWER SWITCH PINS, SHOWN ON P1, SHOULD BE CONNECTED TOGETHER TO
TURN THE PROCESSOR UNIT ON AND DISCONNECTED TO TURN IT OFF. IF A SKYWATCH
CONTROL/DISPLAY UNIT IS NOT IN THE INSTALLATION, A DEDICATED SWITCH MAY BE REQUIRED
TO TURN THE SKYWATCH PROCESSOR UNIT ON OR OFF.
4.
THE BENDIXKING/RYAN TAS PROCESSOR SWITCH PIN (P1-16) SHOULD BE GROUNDED TO TURN
THE PROCESSOR UNIT ON, AND OPEN TO TURN THIS UNIT OFF. IF A RYAN TCAD DISPLAY UNIT IS
NOT IN THE INSTALLATION, A DEDICATED SWITCH MAY BE REQUIRED TO TURN THE TAS
PROCESSOR UNIT ON AND OFF.
5.
IF ANY OF THESE TRAFFIC SYSTEMS ARE INSTALLED WITHOUT A CONTROL/DISPLAY UNIT, A
PLACARD IS REQUIRED NEAR THE AERONAV UNIT, INDICATING THAT A TRAFFIC ADVISORY
SYSTEM IS INSTALLED, AND ITS DATA MAY BE DISPLAYED ON THE AERONAV UNIT.
6. REFER TO MANUFACTURER’S DOCUMENTATION FOR COMPLETE PINOUT AND INTERCONNECT
INFORMATION. PINOUTS OF OTHER INPUTS SHOWN FOR REFERENCE ONLY.
7.
IN ORDER FOR SKYWATCH DATA TO BE DISPLAYED ON THE AERONAV UNIT’S MAP PAGE, THE
AERONAV UNIT MUST HAVE A DIGITAL HEADING SOURCE, OR THE SKYWATCH MUST HAVE A
SYNCHRO OR SERIAL HEADING SOURCE. A STEPPER HEADING SOURCE WILL NOT ALLOW
SKYWATCH DATA TO BE DISPLAYED ON THE MAP PAGE.
8. AT AERONAV UNIT, TERMINATE SHIELD GROUNDS TO THE CONNECTOR BACKSHELL OR USE
CARD-EDGE CONNECTOR SHIELD GROUNDS TO AIRCRAFT CHASSIS WITH AS SHORT A
CONDUCTOR AS PRACTICAL.
9. REFER TO SECTION 7.0 FOR ARINC 429 AND FOR RS-232 SETTINGS. IF AN ARINC 429 TRAFFIC
SOURCE IS USED, THE CORRESPONDING ARINC 429 INPUT MUST BE SET TO HIGH SPEED.
10.
KTA 870/KMH 880/KTA 970/KMH 980 SYSTEMS MUST HAVE TRAFFIC CONFIGURED FOR
“CONTROLLER TYPE: DISCRETE” AND “DISPLAY VALID: IGNORE”.
11.
SKYWATCH MUST BE CONFIGURED FOR AN ARINC 735 TYPE 1 DISPLAY.
12. FOR GTX 8XX CONFIGURATION SETTINGS, SEE THE GTX 8XX INSTALLATION MANUAL.
THE P1050 CONNECTOR IS NOT AVALIABLE ON AERONAV 780/800 UNITS.
2
3
4
7
9
10
11
12
13
