BENDIXKing KSN 8 Series - Page 219

89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page F-8
© Honeywell International Inc. Do not copy without express permission of Honeywell.
GNS-530/W or 430/W – DATE / TIME SETUP Page
(No Need to Fill In – For Reference Only)
UTC DATE UTC TIME
GNS-530/W or 430/W – MAIN DISCRETE I/O Page
GRAY
CODE
DECODED
ALTITUDE
EXTERNAL SWITCH STATE
RMT CDI OBS
DISCRETE
TOGGLE
APR OBS
ILS/GPS APR
GPS TERM
INTEG VLOC
MSG WPT
Note: Check off the squares, as required, to
match the solid squares on the GNS-
530/430 unit – these check that discretes
are wired correctly.
No AeroNav XXX Equivalent
AeroNav XXX – MAIN DISCRETE I/O Page (6/12)
GRAY CODE DECODED ALTITUDE
EXTERNAL SWITCH STATE
RMT CDI RMT OBS RMT RCL
TER INHB AUD INHB
DISCRETE TOGGLES
APR OBS ILS/GPS APR
GPS TERM GPS SELECT
INTEG VLOC TER CAUT
MSG WPT TER INHB
TER N/A
TER WARN
Note; ON or OFF will be Displayed
