GNS-530/W or 430/W – MAIN CDI / OBS CONFIG
Page
CDI NAV
FLAG
TO-
FROM
LAT
VERT
SELECTED COURSE
CDI OBI
SOURCE
V-FLAG
STATE
AeroNav XXX – MAIN CDI / OBS CONFIG Page
(7/12)
CDI NAV
FLAG
TO-
FROM
LAT
VERT
SELECTED COURSE
Ignore SEL
CRS for
GPS
Ignore SEL
CRS for
VLOC
CDI OBI
SOURCE
V-FLAG
STATE
For new AeroNav XXX installations, see
Section 7.5.8 for selections and
descriptions.
GNS-530/W or 430/W – COM SETUP Page (GNS-
530W/430W Only)
FREQ SQ 250
SPACING SQ 833
SIDETN
MIC
STORE CALIBRATION?
PTT XFR RX TX
No AeroNav XXX Equivalent Page
(Use the User Options tab to select 25 or 8.33 kHz
spacing)
Note: The squares above do not need to be
recorded – they fill in when/if that function
is activated.
