BENDIXKing KSN 8 Series - Page 221

89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page F-10
© Honeywell International Inc. Do not copy without express permission of Honeywell.
GNS-530/W or 430/W – VOR/LOC/GS CDI Page
CDI NAV
FLAG
SPR
FLAG
TO-
FROM
LAT
VERT
SELECTED COURSE
DME
CHANNEL
MODE
GNS-530W or GNS-430W Only
AeroNav XXX – VOR/LOC/GS CDI Page (8/12)
CDI NAV
FLAG
SPR
FLAG
TO-
FROM
LAT
VERT
SELECTED
COURSE
DME
CHANNEL
MODE
For new AeroNav XXX installations, see
Section 7.5.9 for selections and
descriptions.
GNS-530/W or 430/W – VOR/LOC/GS ARINC 429
CONFIG Page (GNS-530W/430W Only)
RX TX
SPEED
SDI
DME MODE
AeroNav XXX – VOR/LOC/GS ARINC 429 CONFIG
Page (9/12)
RX TX
SPEED
FORMAT
SDI
DME MODE
For new AeroNav XXX installations, see
Section 7.5.10 for selections and
descriptions.
GNS-530/W or 430/W– GPS Vertical Offset
(if present)
GPS Antenna Height Above
Ground
AeroNav XXX – GPS Antenna Setup Page (10/12)
GPS Antenna Height Above
Ground
Antenna Type
Note: Use the data recorded at the
beginning of Appendix F to enter the
Antenna Type field.
