89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page F-11
© Honeywell International Inc. Do not copy without express permission of Honeywell.
GNS-530/W or 430/W– STORMSCOPE CONFIG Page
(if configured for Stormscope)
STATUS: MODE:
SW VERSION: ANT MOUNT:
HDG FORMAT HDG FLG SENSE
HDG FLAG SYNC ANGLE
HDG STAB SYNC REF
HDG VALID
Note: Squares should all be green if no
issues.
GNS-530/W or 430/W – STORMSCOPE TEST Page
(if configured for Stormscope)
MODE
STATUS
TRIGGER COUNT
HDG
AeroNav XXX STORMSCOPE CONFIG Page
(Software version 10.2 or higher)
Accessible via the TEST page, select GET
DATA, scroll to Config, and record the
jumpers installed and grounded
HEADING
INPUT
J3-1 OPEN GND
J3-2 OPEN GND
HEADING
FLAG
SENSE
J3-4 OPEN GND
ANTENNA
MOUNT
J3-3 OPEN GND
AeroNav XXX – STORMSCOPE TEST Page
(Software version 10.2 or higher)
MODE
STATUS
TRIGGER COUNT
HDG
