89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page F-12
© Honeywell International Inc. Do not copy without express permission of Honeywell.
GNS-530/W or 430/W– STORMSCOPE DATA
DOWNLOAD Page (if configured for Stormscope)
SOFTWARE VERSIONS:
Model
Main SW Ver
Main Boot SW Ver
DSP SW Ver
GNS-530/W or 430/W – Traffic Config Page
(if configured for Traffic)
ALT
LIM A (if 429
interface)
LIM B (if 429
interface)
HDG (if 429
interface)
BARO ALT
(if 429 interface)
RAD ALT
(if 429 interface)
TEST MODE?
(if 429 interface)
AeroNav XXX – STORMSCOPE DATA Page
(Software version 10.2 or higher)
No AeroNav XXX Equivalent Page
Note: Traffic monitoring is accomplished
after a 3 minute suppression period in-flight
when any faults are announced. There
should be no Red-X on the traffic thumbnail
if configured on the Setup pages.
Note: Check off the squares, as required, to
match the solid squares on the GNS-530
unit.
SOFTWARE VERSIONS:
Model
Main SW Ver
Main Boot SW Ver
DSP SW Ver
To Next Page
