Selection Description
Shadin-Fuel
Serial fuel flow information from the following units:
Shadin 91053XP and 91053XT-D “Digiflo-L” Digital Fuel Management
Systems
Shadin 91204XX(38)D and 91204XT-D “Miniflo-L” Digital Fuel Management
Systems
JP Instrument EDM-700 or EDM-760 Engine Monitor
Other JPI systems (e.g. JPI FS-450) can use this setting but see the specific
format guidance from JPI for the Garmin GNS series.
WX-500 Serial lightning data information from the L3 Communications WX-500
Stormscope
TWX
Serial lightning data information from the Avidyne TWX670 in “Native”
format
Vhf Ctrl Reserved for future VHF remote control
Table 82 RS-232 Input Selection
1
These weather receiving devices are mutually exclusive. Only one source can be displayed at
one time. Both weather sources can be wired to the AeroNav so that the higher priority
weather overlay can display on the AeroNav and the lower priority weather data can be
streamed out of the AeroNav via WiFi for display on a compatible tablet/wireless device
application. The current display priority is GDL-69, MLB700, AV300/350, MLB/SkyTrax100.
2
These Traffic receiving devices are mutually exclusive. Multiple devices should not be
installed/configured on a single unit.
Channel Outputs
Selection
Description
Off
No device(s) connected to output of this channel
ADS-B (Avi)
3
Serial position data to the following units:
Trig TT31 (V 3.1 or later)
Avidyne AXP340
ADS-B+ (G)
Garmin GTX 330 Low Speed 9600 Baud
ADS-B+ (G2)
Garmin GTX 335/GTX345/GDL 88 High Speed 38,400 Baud
Aviation
3
Serial position, altitude, velocity, and navigation data to the following
units:
Argus 3000, 5000, or 7000 Moving Map
Avidyne FSD Series
Garmin MX20 (V5.6 or later), GMX200
Garmin GPSMAP 195, GPSMAP 295 or GPS III Pilot
Garmin GPSMAP 196, GPSMAP 296, and GPSMAP 396
Garmin GPSMAP 496, and GPSMAP 696
Garmin Aera 796/795
Garmin GTX 327 Transponder
JP Instruments EDM-700 or EDM-760 Engine Monitor
Shadin 91204XM Digital Fuel Management System
Shadin 91053XP Digital Fuel Management System
Shadin 9628XX-X Fuel/Air Data Computer
Stormscope Series II (with NAVAID) Moving Map
