89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page 7-11
© Honeywell International Inc. Do not copy without express permission of Honeywell.
Selection
Description
Aviation no Alt
3
Serial position, velocity, and navigation data to the following units:
Garmin MX20 (V5.5 or earlier)
Horizon DDMP
Insight TAS 1000 Air Data Computer
AXP322
Select for Avidyne AXP322 Remote Transponder
CrossSync Serial transfer of flights plans and user waypoints and cross-side data
(e.g. Datalink, traffic, lightning, etc) between AeroNav XXX units
Note: This is only an option for CHNL 3.
GDL 69
1
Serial data output to a Garmin GDL69/69A P/N 011-00986-00 or 011-
00987-00 only (Garmin software version 4.01 or later) pre Avidyne
software 10.2.3.1. With software 10.2.3.1 and later P/N 011- 03177-X0
will also work
MLB700
1
Serial weather data information to the Avidyne MLB700 and WSI AV-300
/ 350
XMD076
1
Serial weather data only information to the Avidyne Skytrax100/MLB100
or Freeflight FDL-978-RX
SkyTrax Trfc
2
Serial traffic data only information to the Avidyne Skytrax100/MLB100 or
Freeflight FDL-978-RX
SkyTrax Trfc+Wx
1,2
Serial traffic and weather data information to the Avidyne
Skytrax100/MLB100 or Freeflight FDL-978-RX
Capstone Trfc
2
Garmin GTX 335/345 and other 3
rd
party compatible ADS-B traffic devices
Capstone Trfc+Wx
1,2
Garmin GTX 345 and other 3
rd
party compatible ADS-B traffic and
weather devices.
Capstone HS Trfc
2
Serial traffic data information from any High Speed Capstone compliant
ADS-B traffic device at 115200 baud.
Capstone HS Trfc+Wx
1,2
Serial traffic and weather data information from any High Speed
Capstone compliant ADS-B traffic device at 115200 baud.
MLB100 Wx
1
Serial weather data only for existing MLB100 installs.
HW EGPWS
3
Serial communication to a Bendix/King (Honeywell) KGP 560 EGPWS
Freeflight
1,2
Serial Freeflight transponder control protocol along with High Speed
Capstone ADS-B traffic and weather data information from a Freeflight
Ranger device.
NGT9000R Serial transponder control protocol to control an L3 NGT9000R remote
mount transponder.
MapMX
3
Serial position, altitude, velocity, and navigation data to the following
units:
Garmin MX20 (V5.7 or later), GMX 200
Ryan TCAD
2
Traffic information to a Ryan 9900B, 9900BX, or TAS6XXA Series System.
WX-500
Serial communication to L3 Communications WX500 Stormscope
TWX
Serial communication to the Avidyne TWX670
Vhf Ctrl
Reserved for future VHF remote control
Table 83 RS-232 Output Selection
1
These weather receiving devices are mutually exclusive. Multiple devices should not be
installed/configured on a single unit.
