89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page 7-13
© Honeywell International Inc. Do not copy without express permission of Honeywell.
GPS Select Selections:
Selection Description
Auto In GPS mode on the AeroNav XXX, the GPS Select discrete will not be
active (open) in a GPS approach, and no messages will annunciate on the
AeroNav XXX and no pilot action is required. This setting allows the pilot
to use the GPS VLOC Capture option on the User Options part of the
Setup tab on the AUX page.
Prompt In dual AeroNav installations, only the AeroNav connected to a KFC225
autopilot should be setup for prompt. In GPS mode, the user will be
prompted to enable the approach in KFC225 equipped aircraft When
Prompt is selected, and a GPS approach mode is active, a CAS message
will prompt the pilot to “Enable A/P Approach” on the FPL tab. At that
point, the pilot may then enter APR mode on the autopilot. This setting
will also ignore the GPS VLOC Capture option on the User Options part
of the Setup tab on the AUX page.
Table 85 GPS Sequencing
Airframe Selections:
Selection Description
Fixed Wing For Fixed Wing installations
Helicopter For Helicopter installations
High Speed For Jet installations
Table 86 Airframe Selection
Tail Number:
Tail number is a text field and is used for various purposes (i.e. Jeppesen data subscription and
transponder function).
External TAWS Selections:
Selection Description
Yes Select if an external EGPWS or TAWS device (e.g. KGP 560) is connected
to the AeroNav XXX. It will disable FLTA and TA functionality as well as
aural alerts in the AeroNav XXX
No Select when no external EGPWS or TAWS device is connected to the
AeroNav XXX, thereby enabling all FLTA and TA functionality on the
AeroNav XXX.
Table 87 External TAWS Selection
Weight on Wheels (WOW)
Selection Description
Yes When set to “Yes” and the Airframe Selection is set to “Helicopter” Pin 70
on P1001 is used as a discrete input to control the in-air or on-ground
state of the AeroNav. Logic state required is “Low when on ground”
No Select “No” when WOW discrete input is unavailable.
Table 88 Weight on Wheels
