42 Multifunction Control Panel
®®
Figure 3.4 - Keypads Page
At default or after a restoration Factory preset, in the Control Panel are auto-
matically programmed one or more keyboards according to as specified in Tab.
6.1 of the Chapter 6 of MAIN UNIT MANUAL.
Keypads Table
This table will allow you to enable (
) or disable (box empty) the system keypads.
No. - This column shows the keypad Address (non editable).
Description - This field is for the keypad label (maximum 16 characters).
The number next to the Page Name indicates the total number of enabled
keypads.
Enable Keypad
This section will allow you to enable (
) or disable (box empty) the keypad on the
partitions.
Keypad Type
This section will allow you to specify the type of keypad (refer to Chapter 2).
Select “LCD” for LCD keypads or select “Icon/Kp - LED” for LED
keypads.
Keypads Page
To Next Page
