65
®®
Section 3 - Programming from PC
Delete button - This button opens the Delete
Logger window, and will allow you to delete the
events from the Hard-Disk.
The events logged between the From - to dates
entered in this window will be deleted when the
OK button is clicked.
Main User Code - This field is for the Main User Code, which will allow
the user to view the Events List (Installer Code NOT required).
Figure 3.13 - Events Page
Events page
The parameters in this page (see Figure 3.13) determine the actions the Control
panel will take in response to the associated events.
Telephone actions:
a) activate the Digital Communicator (Pulse);
b) activate the Voice Dialler.
This section describes the ‘Event Settings’ table (see Table 3.3 for the complete
list of Programmable Events).
z No. - This column shows the Event Identifier Numbers.
z Description - This column shows the type of events the Control panel can
manage (see Table 3.3 in the following pages).
z Telephone Number - The Telephone Number table will allow you to assign
Telephone numbers to the various events. The selected Telephone Numbers will
be called when the corresponding event occurs (see the Figure in the left margin).
