64 Multifunction Control Panel
®®
Figure 3.12 - Logger Page
Logger Page
This window (see Figure 3.12) will allow you to view the events recorded in the
Logger.
z No. - This is the event number.
The rotating Logger holds 256 events (128 on Series 4-8 Models). When
the Logger is full, the oldest events will be deleted to make space for new
events.
z Date - Date when the event occurred.
z Time - Time when the event occurred.
z Event Type - Event description.
The following commands will allow you to manage the events:
Upload button - This command will allow you to upload the Events list from
the Control panel to the Computer for viewing purposes.
Print button - This command will allow you to print the entire Events list.
The following buttons will become active when a Customer is loaded. The name of
the Customer will be shown on the title bar.
Save button - This command will allow you to save the events on the Hard-
Disk. Each Customer will have an Events file. The Application will create
the file when the first ‘Save’ request is made.
Load button - This command will allow you to view the events stored on
the Computer Hard-Disk.
