50 Multifunction Control Panel
®®
The ‘Vibration’ and ‘Roller Blind’ attributes can be assigned to the first
6 Control panel zones only (all zones for Kyo4 and only on the first 2
zones for Kyo16D).
z Wireless (Wireless) - (Only for 8W, 8GW, 16D, 32 and 32G models).
Only systems with a duly enabled VRX32-433 or Vector/RX8 Receivers
(refer to ‘Options’ in this section) can manage zones with this attribute. The
6 digit Serial Numbers of devices connected to these zones must be specified
in the respective column. If a zone is setup as a Wireless zone, the Super-
visory attribute will be enabled automatically (refer to ‘Supervisory’), and
it will be shown in red.
IMPORTANT - If the “Low Battery” fault warning persists after the
batteries have been changed, deselect the “Wireless” attribute of the
respective zone then re-select it immediately.
z Supervisory (Superv.) - If a zone is setup as a Wireless zone, this at-
tribute will be enabled automatically, thus allowing the VRX32-433 or Vector/
RX8 Receiver to monitor the Wireless device that is connected to the zone
(refer to ‘Supervisory Time’ on the ‘Partitions’ page). If the Wireless device
fails to send a signal to the VRX32-433 or Vector/RX8 Receiver within the
programmed Supervisory window, the Control panel will generate a ‘Miss-
ing Device’ event.
The Identifier number of the zone which generated the event will be
recorded in the Event logger.
z Double (Double P) - A Zone with this attribute will generate an Alarm if it
is violated twice within the programmed time (accepted values: 0 through
250 seconds). Refer to the ‘Double Pulse’.
z Or (Or) - Violation of a Zone with this attribute will generate an Alarm even
when only ONE of its Partitions is Armed.
z And (And) - Violation of a Zone with this attribute will generate an Alarm
only when all the ‘And’ Zones of the Partition concerned are violated within
the programmed Time (refer to ‘T. And Zone’ on the Partitions page).
