85
®®
Section 3 - Programming from PC
'/'*
'*
?]^YQ>_b]Q=?45=f
HHH
This is the type of Modem that is connected to the computer serial port
E^[^_g=_TU]
The configured Modem is not recognized or does not respond. Check the cable and the
serial port connection.
BUSUYfY^W
The Modem/PC system is waiting for an incoming call. This is the system status when
the 'CONNECTIONS' window opens
213;B9>7
The dialled telephone number is ringing
;I?h13;
KYO Panel Control has been recognized
Gb_^W
9^cdQ\\Ub3_TU
The remote Control panel cannot read the Installer PIN — probably due to a bad line
2eci<Y^U_^8__[
The Modem has detected the engaged tone and has released the line
When the Connection Window opens, parameters b), c) and d) will assume the
values of their counterparts in the ‘Teleservice Page’ or ‘Phone Page’.
The parameters programmed in the ‘Connection Window’ will not affect
their counterparts in the Application pages.
5. Click the Select button (below the ‘Messages’ section) to view the connec-
tion status. Table 3.4 shows the complete Message list. If the connection is
successful, the following message will be shown:
KYOxACK
X.XX
Connections
6. Click the OK button to close the ‘Connection Window’, and activate the
connection. All Download and Upload commands will affect the Control
panel that is connected via telephone.
7. To program or view the Control panel parameters, go to the ‘Programming
from PC’ section, and proceed from steps 3 and 4.
8. To end the connection, select Modem Hang up. The ‘Connection ended’
message will be shown after several seconds.
To abandon the telephone connection, click the Quit button.
