BERNINA 720
User Manual

Table of Contents

Questions and Answers

  • S
    Shannon WeberAug 19, 2025
    Why does my Bernina 720 have uneven stitches?
    • N
      Noah HicksSep 12, 2025
      Uneven stitches can occur if the upper thread tension is either too tight or too loose; adjust it accordingly. Other potential causes include a blunt or bent needle (replace it with a new BERNINA quality needle), a poor-quality needle (use a new BERNINA quality needle), poor-quality thread (use quality thread), an incorrect needle/thread combination (match them appropriately), incorrect threading (rethread the machine), pulling the fabric (feed it evenly), or using the incorrect bobbin case (use the supplied bobbin case with triangles).
  • K
    Kelsey ChaseAug 21, 2025
    What to do if my Bernina 720 Sewing Machine is skipping stitches?
    • D
      David SimsAug 21, 2025
      Skipped stitches on your Bernina Sewing Machine may be due to using the incorrect needle; ensure you are using the 130/705H needle system. A blunt or bent needle can also cause this issue, so replace it. Similarly, using a poor-quality needle can lead to skipped stitches, so use a new BERNINA quality needle. Check that the needle is correctly inserted with the flat side to the back, as far up as it will go, and that the screw is tightened. Finally, the incorrect needle point can cause skipped stitches; match the needle point to the texture of the material.
  • R
    Rachel PierceAug 25, 2025
    How to fix faulty stitching on my Bernina Sewing Machine?
    • T
      timothyhuntAug 25, 2025
      Faulty stitching on your Bernina Sewing Machine can arise from thread remnants between the thread tension discs; fold a piece of thin material and slide the folded edge between the discs to remove them. Ensure the machine is correctly threaded by rethreading it. Additionally, check for thread remnants below the bobbin case spring and remove them if present.
  • M
    Maria LopezAug 26, 2025
    What to do if my Bernina Sewing Machine doesn't start?
    • E
      eric21Aug 26, 2025
      If your Bernina Sewing Machine doesn't start, it could be due to an unfavorable room temperature. Place the machine in a warm room one hour before use, then connect the machine and switch it on. If this doesn't work, the machine may be damaged; contact a specialized BERNINA dealer.
  • A
    Anthony WhiteAug 28, 2025
    How to fix error during software update on Bernina 720?
    • M
      Micheal ScottAug 28, 2025
      An error during a software update on your Bernina Sewing Machine can occur if the USB stick is not recognized; use a BERNINA USB stick. If the update process is blocked and the hourglass on the display is inactive, remove the USB stick, switch the machine off, and then switch it back on. Follow the instructions on the display, unzip the update data, and save the software update data directly on the data medium, not in a file on the USB stick.
  • S
    Stephanie HayesAug 30, 2025
    Why does the upper thread keep breaking on my Bernina 720?
    • M
      Mr. Mark RobertsAug 30, 2025
      Upper thread breaks on a Bernina Sewing Machine can be caused by an incorrect needle/thread combination, so ensure they are properly matched. If the upper thread is too tight, reduce the tension. Also, check if the machine is incorrectly threaded and rethread it if necessary. Using poor quality thread can also cause breakage, so switch to quality thread. If the stitch plate or hook tip is damaged, contact a specialized BERNINA dealer for repairs. Finally, if the thread is caught in the area of the thread take-up lever, remove the screw on the headframe with the angular Torx wrench, pull the headframe slightly forward, flip it upwards, remove the headframe, remove any thread remnants, reattach the headframe, and tighten the screw.
  • V
    Victoria BennettSep 1, 2025
    Why does the needle keep breaking on my Bernina Sewing Machine?
    • A
      Amanda LoveSep 1, 2025
      Needle breakage in a Bernina Sewing Machine can occur if the needle is incorrectly inserted; make sure to insert the needle with the flat side to the back as far up as it will go and tighten the screw. Pulling the fabric can also cause the needle to break, so feed the fabric evenly. If you are pushing thick fabric, use the correct presser foot designed for thick materials, such as jeans. Using knotted thread can also lead to needle breakage, so ensure you are using quality thread.
  • H
    Heather SanchezSep 3, 2025
    What causes the lower thread to break on my Bernina 720?
    • M
      Michelle SantosSep 3, 2025
      Lower thread breaks on a Bernina Sewing Machine may be due to a damaged bobbin case; replace it if necessary. If the stitch hole in the stitch plate is damaged, contact a specialized BERNINA dealer for repairs. A blunt or bent needle can also cause the lower thread to break; replace the needle.
  • W
    Willie TurnerSep 5, 2025
    What to do if the display on my Bernina 720 Sewing Machine is inactive?
    • S
      Sean LopezSep 5, 2025
      If the display on your Bernina Sewing Machine is inactive, it could be due to incorrect calibrating data. To resolve this, switch the machine off, then switch it back on while simultaneously pushing and holding the «Needle left/right» button to recalibrate the display. Alternatively, the eco-function might be active; touch the «eco» icon to deactivate it.
  • S
    Stephanie MillerSep 7, 2025
    Why is the sewing speed too low on my Bernina 720?
    • P
      petersonchelseaSep 7, 2025
      If your Bernina Sewing Machine's sewing speed is too low, it might be due to an unfavorable room temperature. Place the machine in a warm room one hour before use. Alternatively, the sewing speed may be set too low in the Setup Program; adjust it accordingly.

Summary

IMPORTANT SAFETY INSTRUCTIONS

Safety Warnings and Guidelines

Essential safety instructions, usage rules, and environmental considerations.

Important Information

Manual, Proper Use, and Symbols

Information on the manual, proper use, scope of delivery, and symbol explanations.

My BERNINA

Machine Components and User Interface

Identification of machine parts and overview of the touch screen interface.

Sewing Preparation

Initial Setup and Threading

Connecting the machine, controls, and threading procedures.

Setup Program

Configuring Settings

Adjusting various machine settings for sewing and embroidery.

Creative Sewing

Stitch Pattern Editing and Management

Modifying, combining, saving, and managing stitch patterns.

Practical Stitches

Stitch Catalog and Techniques

Overview of practical stitches and guides for common sewing applications.

Decorative Stitches

Decorative Stitch Overview and Techniques

Categories of decorative stitches and techniques like pintucks.

Buttonholes

Buttonhole Operations and Sewing

Overview, types, marking, sewing, and finishing buttonholes.

Quilting and BSR Usage

Quilt Stitches and Free-Motion Techniques

Catalog of quilt stitches and guidance for free-motion quilting.

BERNINA Stitch Regulator (BSR) Operation

Setup, modes, and usage of the BSR for consistent stitch length.

Embroidery Operations

Module Preparation and Creative Embroidering

Module setup, hoop management, motif editing, and combining.

Embroidery Execution and Speed Control

Starting embroidery, adjusting speed, and thread tension for embroidery.

Care, Maintenance, and Troubleshooting

Firmware, Cleaning, and Fault Resolution

Firmware updates, machine cleaning, lubrication, and error troubleshooting.

Storage, Disposal, and Technical Data

Storage, Disposal, and Specifications

Guidelines for storing, disposing, and technical specifications of the machine.

Stitch Pattern and Embroidery Motif Catalogs

Visual Catalog of Stitches and Motifs

Visual guide to practical, decorative stitches, and embroidery motifs.
