BEUMER stretch hood® S
Installation
BA-6090103-EN
19.08.09
39
The plates for the platform are supplied separately. The arrangement of the
plates is shown on the illustration. The individual plates are bolted to the sub-
structure and with one another.
1 Plates
2 Hoist
How to mount the
platform
1. Place the plates on the substructure and fasten them slightly by bolts.
2. As soon as all plates have been placed on the substructure, bolt them with
one another.
3. Align the plates and tighten all screw and bolt connections.
