“ICON2000”
instruction and operating manual
Item
1
2
3
4
5
5.1
6
7
8
9
10
Cable type
CAB0100
CAB0150
CAB0160
CAB0270
CAB0350
CAB0354
CAB0280
CAB0300
CAB0200
CAB0250
CAB0170
Description
I/O remote cable
Remote control supply cable
Inlet power cable
Motor power cable
Speed sensor cable
Speed sensor cable
Thermostat cable
Position sensor cable
Internal controls cable
Contactor controls cable
Earth wire
• Recommended spare parts
ICON2000 - Wiring loom and cables identification table 8
ICON2000 - Wiring loom and cables identification table 8
10
3
5
6
1
2
7
9
8
4
5.1
Section 618/4 chapt. O
