74
© Copyright by BIFFI Italia. All rights reserved.
“ICON2000”
instruction and operating manual
Section 618/2 chapt. I
Section 618/2
2. Valve data
The valve data allow identifying the valve and its function in the process. The valve
manufacturer and the end user can enter the data. The following data can be entered:
• tag name (max. 28 char.)
• serial number (max. 28 char.)
• manufacturer (max. 28 char.)
2.1 SAMPLE CONFIGURATION PROCEDURE: TAG NAME
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language and enter the password according to the instructions (see “Entering the set-
up mode”). When the message displayed is “SET-UP MODE OK?” press YES. Press NO
to scroll the list of available menus and then press YES to select valve data menu.
• Press NO to scroll the list of available routines and then press YES to select Tag name.
• Press YES if the 1st character of the string is correct. Press NO to scroll the list of available
characters. Press YES to select the desired character.
• Enter up to 28 characters. Enter a blank character, and “ ” as end of string.
The configuration of all other valve data items is made in the same way, by selecting the
relevant item from the list of available routines.
3. Maintenance
A large amount of data is stored in the actuator memory and is available for future analysis
or to assist the operator in the maintenance program. The maintenance menu also includes
the set password routine, and the possibility to modify or start the maintenance functions.
The following data are available:
• set password
• clear alarm log
• set torque reference
• set curve reference
• clear recent data log
• set maintenance date
• set data logger
3.1 SET PASSWORD
The actuator is supplied by BIFFI with a default password (“0 0 0 0”). By the above routine
the end user can enter a different password consisting of 4 alphanumeric characters. After
entering the new password, the old one ceases to be valid. Therefore it is mandatory “NOT
TO FORGET THE PASSWORD” after the default one has been modified. Forgetting the new
password makes it impossible to enter the set-up menu and to configure the actuator.
• break OP torque (max. 28 char.)
• break CL torque (max. 28 char.)
• max stem thrust (max. 28 char.)
• flange type (max. 28 char.)
