BIFFI ICON 2000 - First-Time Operation

35
© Copyright by BIFFI Italia. All rights reserved.
“ICON2000”
instruction and operating manual
Section 618/2 chapt. E
Section 618/2
If the following message appears, the base card is
ICON2000 v4 type, but the actuator is equipped with
an ICON2000 v0 series terminal board. This may
happen if the ICON2000 v4 base card was supplied as
a spare card, to replace the base card of the ICON2000 v0 series (see the previous revision
of instruction manuals relevant to the ICON2000 and its optional modules).
Do not operate the actuator without first checking that the configuration is according to the
required application by using the “VIEW and SET-UP” features (see Sect. 618/2 chap. F,
…., L). Set torque limits, position limits and close direction by means of the “stroke limits
routine” of the “actuator set-up” menu (see Sect. 618/2 chap. I). When the stroke limits and
the configurations are correct, bring the 3-position selector to LOCAL and drive the actuator
to open or closed position (see Sect. 618/2 chap. E par. 3).
8. Optional modules
Additional modules can be plugged in the base card of the ICON2000 to provide the
following functions:
8.1 FIELDBUS INTERFACE FOR REMOTE CONTROL VIA FIELDBUS
This card allows to connect the ICON2000 to FIELDBUS.
The following bus interface cards are available:
 Profibus DPVO
 Profibus DPV1 with or without redundancy
 Foundation Fieldbus
 LonWorks
 Modbus RTU
7. Operating the ICON2000 for the first time
Before attempting to operate the ICON2000 for the 1st time, check that the actuator is
correctly mounted on the valve. Place the 3-position selector in OFF and switch the power
on. The alphanumeric display shows the following message for about 3 seconds:
Biffi Italia
ICON2000 v4 ntb
Then the new message should be:
NORMAL OFF or
STOP
according to the configuration present in the memory.
If the upper line of the display shows “ALARM OFF”, remove the alarm before going
ahead (see Sect.618/3 chap. N, par. 11).
If the upper line of the display shows “WARNING OFF”, a warning condition is
present. You can go ahead since the ICON2000 is working well, but some datum is not
according to the configured parameters (see Sect.618/3 chap. N, par 11).
If the upper line of the display shows “INT OFF”, an Interlock input is active.
If the upper line of the display shows “ESD ON OFF”, the ESD input is active.
NORMAL OFF
R%: xxx.x
Biffi Italia
ICON2000 v4 otb
