VIEW ROUTINES
1. Actuator set-up
The above menu allows to view the present actuator configuration. No change can be made
to the present data. The following data can be viewed:
ROUTINE PARAMETERS
The routines with * can only be viewed if the relevant electronic cards are present. If the bus
interface is LonWorks, routine “BUS” changes to “FDI control”. Detailed descriptions of the
above routines and their parameters can be found in Chapter I.
View procedure:
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language according to the instructions (see “Entering the view mode”). When the
message displayed is “VIEW MODE OK?” press YES. Press YES to select the actuator
set-up menu.
• Press NO to scroll the list of available routines and press YES to select.
• Press YES to answer at the prompt “view” or “next” and to see the data
79
© Copyright by BIFFI Italia. All rights reserved.
“ICON2000”
instruction and operating manual
Section 618/2 chapt. L
Section 618/2
• stroke limits
• torque set-up
• ESD control
• remote controls
• local controls
• output relays
• Positioner *
• Fail Safe *
• Out 4-20mA *
• Interlock
• 2-speed timer
• Bus *
• miscellaneous
• close direction (CW, CCW), close limit type (torque
or position), open limit type (torque or position)
• closing torque limit %, opening torque limit %
• ESD action, signal type, ESD priority
• control type
• control type, LED’s colour
• monitor relay conditions, ASi conditions, contact
action
• dead band, motion inhibit time, polarity, %min,
%max (%min and %max are present only if
“position request R%” is from 4-20mA input)
• action, delay
• output signal (position or torque), polarity
• Signal type in OP, signal type in CL
• close direction: status, start, stop, on time, off time
• open direction: status, start, stop, on time, off time
• Node address, terminations, etc. depending on
fieldbus type
• time and date, torque mode, lithium battery, torque
by pass %, valve jammed time
