BIFFI ICON 2000 - Acyclic Communication Dpv1; Name Plate

“ICON 2000v4"
instruction and operating manual
© Copyright by BIFFI Italia. All right reserved. Section 618/42 Page 20
Contents may change without notice
10.2 ACYCLIC COMMUNICATION DPV1
This paragraph defines the composition of the acyclic communication defined as per PROFIBUS
DPV1.
10.2.1 Name plate
Slot 0, Index 0, length 26 byte: Actuator type
Byte
Name
Dim
Range
EU
0-15
Actuator Type
16 byte
BIFFI ICON 2000
BIFFI F01 2000
16-25
Software revision *
10 byte
String ##
* if the char ‘decimal point’ (ASCII 0x2e) appears in the Software revision string the actuator is a BIFFI ICON2000;
if the char ‘comma’ (ASCII 0x2c) appears the actuator is a BIFFI F01 2000
## the Software revision string is made up of the base software revision and PROFIBUS interface revision with this
format:
SW rev base (4 byte) – obj #5
blank
blank
SW rev interface (4 byte)
Slot 0, Index 1, length 28 byte: Actuator Serial number
Byte
Name
Dim
Range
EU
0-27
Serial number
28 byte
String
Slot 0, Index 2, length 28 byte: Valve Tag name
Byte
Name
Dim
Range
EU
0-27
Valve Tag name
28 byte
String
