“ICON 2000v4"
instruction and operating manual
© Copyright by BIFFI Italia. All right reserved. Section 618/42 Page 27
Contents may change without notice
Configuration procedure:
Move the local selector to OFF and then press simultaneously OPEN and STOP. Select the
language and then enter the password according to the instructions “entering the set-up mode”.
When the message of display is “SET-UP MODE OK?” press YES. Press YES to select
“ACTUATOR SET-UP” menu, press NO to scroll the list of available routines and then press
YES to select BUS CONTROL.
Press YES if the condition linked to DIN 1 is correct, or press NO to change, then press YES.
Repeat the previous step for DIN 2, DIN 3,…,DIN 6
Press YES if the configured value of the node address (NODE) is correct (from 1 to 126), or
press NO to change, then press YES.
Press YES if the configured value of the node address (NODE-B) is correct (from 1 to 126), or
press NO to change, then press YES.
Press YES if the configured status of termination 1 (TERMIN 1) is correct (ON / OFF), or press
NO to change, then press YES.
Press YES if the configured status of termination 2 (TERMIN 2) is correct (ON / OFF), or press
NO to change, then press YES.
Press YES if the configured MODE is correct (CH1, CH2, AUTO), or press NO to change, then
press YES.
View procedure:
Move the local selector to OFF and then press simultaneously OPEN and STOP. Select the
language and then enter the password according to the instructions “entering the view mode”.
When the message of display is “VIEW MODE OK?” press YES. Press YES to select
“ACTUATOR SET-UP” menu, press NO to scroll the list of available routines and then press
YES to select BUS CONTROL.
Press YES to scroll the list of BUS CONTROL parameters.
11.2 NODE REPORT
The following procedure allows seeing the most significant info relevant to the bus data
transmission of the Active Slave.
The following indication are reported:
CARD REPORT: by this routine it is possible to shows the 64 characters identification string
relevant to the Active Slave interface card.
