BIFFI ICON 2000 - Page 259

“ICON 2000v4"
instruction and operating manual
© Copyright by BIFFI Italia. All right reserved. Section 618/42 Page 28
Contents may change without notice
 STATUS 0 this information are get from the Active Slave PROFIBUS module.
b7
b6
b5
b4
b3
b2
b1
b0
Description
x
Status of the Active Slave
1 = active
x
Status of the Primary Slave
1 = active
x
Status of the Backup Slave
1 = active
x
x
Status of the internal Data Area
0 0 = Data Area empty
0 1 = Data Area being read from base card
1 0 = Data Area completely transferred
 STATUS 1 this information are get from the Active Slave PROFIBUS module.
b7
b6
b5
b4
b3
b2
b1
b0
Description
x
x
x
x
reserved
x
x
DP state
00= ‘Wait_Prm’ state
01= ‘Wait_Cfg’ state
10= ‘DATA_EX’ state
x
x
Watchdog State
00= ‘Baud_Search’ state
01= ‘Baud_Control’ state
10= ‘DP_Control’ state
 STATUS 2 this information are get from the Active Slave PROFIBUS module.
b7
b6
b5
b4
b3
b2
b1
b0
Description
x
x
x
x
Baud rate of PROFIBUS communications:
0000= 12 Mbaud
0001= 6 Mbaud
0010= 3 Mbaud
0011= 1.5 Mbaud
0100= 500 Kbaud
0101= 187.5 Kbaud
0110= 93.75 Kbaud
0111= 45.45 Kbaud
1000= 19.2 Kbaud
1001= 9.6 KBaud
x
x
x
x
Current MODULE selected for PROFIBUS cyclic communications
0000= No module selected
0001= 1 Byte output, 2 Bytes input
0010= 4 Bytes output, 8 Bytes input
 STATUS 3 reserved.
 NODE RESET by this routine it is possible to force a reset to the PROFIBUS interfaces
connected to the base card restoring the conditions defined in the BUS
CONTROL menu.
View procedure:
 Move the local selector to OFF or REMOTE and then press YES until the display shows NODE
REPORT. Press NO to exit or press YES to scroll the list of transmission info
