2. Name plate
Use this menu to view the data identifying the actuator. The data are entered in-house and
can only be changed by the manufacturer. The following data may be viewed:
 Serial number: max. 28 characters, univocal identifier of the actuator by reference to
BIFFI acknowledgment.
 Actuator type: max. 28 characters, describes the type of actuator with reference to BIFFI
catalogue
 Torque / Thrust: nominal torque or thrust of actuator
 Actuator speed: nominal speed of actuator
 Power supply: nominal voltage and frequency of actuator
 Motor data: includes the following data relevant to the electrical motor:
• Power type (3ph, 1ph, dc)
• Power rating, max. 99.9 KW
• In, max. 99.9 A
• Is, max. 99.9 A
• Icc, max 999.9 A
 Test date: date of the in-house functional test of actuator
 Wiring diagram (WD): wiring diagram number, max 28 characters
 Enclosure: type of enclosure (Eex-d, etc), max 28 characters
 Certificate: number of certificate, max. 28 characters
 Lubricant: type of lubricant, max. 28 characters
 Revision: HW revision of base card, SW revision of H8 microprocessor, SW revision of PIC
microprocessor
 Torque sensor: data relevant to the relationship between motor torque and speed. This set
of data also includes the factory torque limit setting, “Torque set CL” and “Torque set OP”.
View procedure:
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language according to the instructions (see “Entering the view mode”). When the
message displayed is “VIEW MODE OK?” press YES. Press NO to scroll the list of
available menus and press YES to select the nameplate menu
• Press YES to answer the prompt “view” or “next” and see the data in the above list
3. Valve data
To identify the valve and its function in the process the following data can be viewed.
• tag name (max. 28 char.)
• serial number (max. 28 char.)
• manufacturer (max. 28 char.)
• break OP torque (max. 28 char.)
The data should be entered by the valve manufacturer or by the end user during set-up
operations.
View procedure:
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language according to the instructions (see “Entering the view mode”). When the
message displayed is “VIEW MODE OK?” press YES. Press NO to scroll the list of
available menus and press YES to select the valve data menu.
• Press YES to answer prompts “view” or “next” and see the data in the above list.
• Duty (S2/15min, etc.)
• Poles (2, 4, etc.)
• Biffi name, max 28 characters
• Gear ratio, max 1000
• break CL torque (max. 28 char.)
• max stem thrust (max. 28 char.)
• flange type (max. 28 char.)
