BIFFI ICON 2000 - Maintenance Info

“ICON 2000v4"
instruction and operating manual
© Copyright by BIFFI Italia. All right reserved. Section 618/42 Page 22
Contents may change without notice
10.2.3 Maintenance Info
Slot 2, Index 0, length 22 byte: general maintenance information.
Byte
Name
Dim
Range
EU
0-1
Actuator position
2 byte
0-1000
2-3
Output torque
2 byte
-100 +100
4-5
Opening time
2 byte
0-65,535
sec
6-7
Closing time
2 byte
0-65,535
sec
8-11
Contactor cycles
4 byte
0-4,294,967,295
unit
12-15
Motor Run Time
4 byte
0-4,294,967,295
hours
16-19
Time Without Power
4 byte
0-4,294,967,295
hours
20-21
Utilisation Rate
2 byte
0-65,535
%
Slot 2, Index 1, length 22 byte: recent maintenance information.
Byte
Name
Dim
Range
EU
0-3
Test Date
4 bytes
dd-mm-20-yy
BCD format
4-7
Recent log date
4 bytes
dd-mm-20-yy
BCD format
8-11
Recent Contactor Cycles
4 bytes
0-4,294,967,295
Unit
12-13
Recent motor Run Time
4 bytes
0-4,294,967,295
hours
14-17
Recent Time Without Power
4 bytes
0-4,294,967,295
hours
18-21
Recent Utilisation Rate
2 bytes
0-65,535
%
Slot 2, Index 2, length 20 byte: Torque profile.
Byte
Name
Dim
Range
EU
0
Reserved
1 byte
1
Opening Break out
1 byte
0-255
%
2
Reserved
1 byte
3
Opening Peak
1 byte
0-255
%
4
Reserved
1 byte
5
Opening Ending
1 byte
0-255
%
6-9
Date Opening
4 byte
dd-mm-20-yy
BCDformat
10
Reserved
1 byte
11
Closing Break out
1 byte
0-255
%
12
Reserved
1 byte
13
Closing Peak
1 byte
0-255
%
14
Reserved
1 byte
15
Closing Ending
1 byte
0-255
%
16-19
Date Closing
4 byte
dd-mm-20-yy
BCDformat
