11. Data at local operator interface
Here below are described the facilities available by the view and setup menu of ICON 2000v4.
11.1 BUS CONTROL
 DIN 1,…, DIN 6 by this routine it is possible to choose the condition that sets the status of
bits DIN1, …,6 of byte 4 when module 2 has been selected. Here below is
the list of the available conditions:
STATUS
ALARM
 open limit
 closed limit
 position >= xx %
 position <= xx %
 closing
 opening
 motor running
 blinker
 mid-travel position
 local selected
 remote selected
 local stop active
 ESD signal on
 manual operation
 motor over-temperature
 over-torque
 over-torque in OP
 over-torque in CL
 valve jammed
 warnings
 valve jammed in OP
 valve jammed in CL
 low alkaline battery (if present)
 mid travel alarm in CL/OP
The following setting is supplied as standard:
 DIN 1: mid-travel position
 DIN 2: local stop active
 DIN 3: motor over-temperature (motor thermostat alarm)
 DIN 4: over-torque (hi_hi torque alarm)
 DIN 5: valve jammed alarm
 DIN 6: mid-travel alarm in OP/CL
 NODE by this function it is possible to enter the PROFIBUS slave node address of
the Primary Slave. The available address range is from 1 to 126. The
address must be selected according to the PROFIBUS network lay-out
where the actuator is inserted.
 NODE-B by this function it is possible to enter the PROFIBUS slave node address of
the Backup Slave. The available address range is from 1 to 126. The
address must be selected according to the PROFIBUS network lay-out
where the actuator is inserted.
 TERMIN 1 status: by this routine the internal termination of the Primary Slave can be
connected to the bus line (ON / OFF). Set “TERMIN 1 = ON” only if the
actuator is at the beginning or at the end of the PROFIBUS line.
 TERMIN 2 status: by this routine the internal termination of the Backup Slave can be
connected to the bus line (ON / OFF). Set “TERMIN 2 = ON” only if the
actuator is at the beginning or at the end of the PROFIBUS line.
 MODE by this routine the redundant or not redundant slave is selected. Set “MODE
= CH1” if a not redundant slave is used: in this case only the Primary
Slave will be present. The option AUTO has to be set when a redundant
slave is used.
